Feed silos

    Home Feed silos

    Feed silos are the smaller version of economical hopper silos. They can be built easily and they have low price. Feed silos are safe. The plate of silos is galvanized 450 g/m2. Feed silos have diameters from 1,83m to 3,66m and cubic capacity from 4 m3 to 77 m3. Roof inclination 40° provides bigger storage capacity than standard 30° therefore the whole capacity of feed silos can be utilized. Discharging can be with a manual (with a wire rope), an electric or capacity control. Side discharger is a perfect solution to discharge a small amount of feed quickly.

    D (m) type Lower
    cone
    angle
    No. of rings Eave height Capacity (m3) Capacity (t)
    1,83 (6’) 60160 60 1 3,5 4 3
    60260 60 2 4,3 6 4
    60360 60 3 5,2 8 6
    60460 60 4 6,0 11 7
    2,14 (7’) 70167 67 1 4,3 7 5
    70267 67 2 5,2 10 7
    70367 67 3 6,0 13 9
    70467 67 4 6,9 16 11
    70567 67 5 7,7 19 13
    70667 67 6 8,6 22 15
    2,75 (9’) 90160 60 1 4,6 11 8
    90260 60 2 5,5 16 11
    90360 60 3 6,3 21 14
    90460 60 4 7,2 26 18
    90560 60 5 8,0 31 21
    90660 60 6 8,8 36 25
    3,66 (12’) 120160 60 1 5,5 16 11
    120260 60 2 6,3 32 21
    120360 60 3 7,2 41 27
    120460 60 4 8,0 50 33
    120560 60 5 8,9 59 38
    120660 60 6 9,7 68 44
    120760 60 7 10,5 77 49

    * The capacity is valid with 640 kg/m3.
